Production capacity
Precision steel casting:
- Materials: carbon, alloy and high-alloy steels with special properties
- Maximum dimensions: length up to 250 mm, diameter/width up to 200 mm
- Weight: from 2 to 2,000 g
- Dimensional accuracy: grade 12-14
- Wall thickness: from 0.8 mm
- Roughness: from Ra 6.3
- Powder metallurgy
- Materials: powder composition corresponding to the required material grade
- Maximum dimensions: height up to 50 mm, length/width up to 100 mm
- Weight: from 1 to 200 g
Mechanical properties:
- Anti-friction material properties - in accordance with TU L 43-84
- Carbon properties - in accordance with GOST 3882-74
Finished products undergo all required control stages:
- X-ray control
- magnetic particle inspection
- crack luminescence
- control of chemical composition, mechanical properties and metal structure state
- dimensional control
- appearance control
